PLACA ASUS PRIME B550M-A WIFI AM4

ASUS PRIME B550M-A (WI-FI): Placa base AM4 con características exclusivas

Preparada para soportar la tercera generación de procesadores AMD Ryzen (llamados Core Matisse), la placa base ASUS PRIME B550M-A (WI-FI) es ideal para diseñar un PC Gaming equilibrado y de alto rendimiento. El soporte de PCI-Express 4.0 te lleva a nuevas alturas. Con soporte para hasta 28 GB de RAM DDR4, tarjetas gráficas PCI-Express 3.0, discos M.2 PCIe 4.0 4x M.2, la placa base ASUS PRIME B550M-A (WI-FI) con su chipset AMD B550 ofrece lo último en rendimiento Gaming.Las placas base ASUS Prime Series están diseñadas y fabricadas para el mercado de consumo, con los mejores componentes y características exclusivas para un alto rendimiento. El overclocking y la alta eficiencia permiten a los usuarios sacar el máximo provecho de tu configuración.

LAS VENTAJAS DE LA PRIME B550M-A (WI-FI) :

Socket AMD AM4 para el procesador AMD Ryzen de 3ª, generación
4 ranuras de memoria DDR4 de 4800 MHz de doble canal (O.C.)
Refrigeración completa: Radiador VRM, radiador PCH sin ventilador, ventilador y ventilador utilitario Fan Xpert 2
Conexiones avanzadas: M.2 PCIe 4.0, USB 3. Tipo-A y Tipo-C
Aura Sync RGB (3 conectores, uno direccionable)
Wi-Fi 6 AX Bluetooth 5.

AMD RYZEN 3000
Los procesadores AMD Ryzen 3000 están entre los primeros procesadores de PC grabados en 7 nm y son compatibles con la interfaz PCIe 4.0. La tercera generación de Ryzen, con el nombre en clave de Matisse, impresiona por sus muchos núcleos e hilos y sus altísimas frecuencias Gaming, creación de contenidos y multitarea intensiva. Hacen que TODO sea más rápido y fluido.

ESPECIFICACIONES TÉCNICAS:

CPU
Build in AMD AM4 Socket 3rd Gen AMD Ryzen&trade, Processors *
Refer to www.asus.com for CPU support list
Chipset
AMD B550
Memory
3rd Gen AMD Ryzen&trade, Processors
4 x DIMM, Max. 28GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/433(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/233 MHz Un-buffered Memory *
Next Generation AMD Ryzen PRO Processors
4 x DIMM, Max. 28GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/433(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/233 MHz Un-buffered Memory *
Dual Channel Memory Architecture
ECC Memory (ECC mode) support varies by CPU.
Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Graphic
x D-Sub
x DVI-D
x HDMI 2.(4K@60HZ)
Expansion Slots
3rd Gen AMD Ryzen&trade, Processors
x PCIe 4.0 x6 (x6 mode)
AMD B550 Chipset
2 x PCIe 3.0 x
Storage
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
3rd Gen AMD Ryzen&trade, Processors :
x M.2 Socket 3, with M Key, Type 2242/2260/2280/220(PCIE 4.0 x4 and SATA modes) storage devices support
AMD B550 Chipset :
x M.2 Socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
4 x SATA 6Gb/s port(s),
Support Raid 0, , 0
LAN
Realtek RTL8H Gb Ethernet
Wireless Data Network
Intel®, Wi-Fi 6 AX200
2x2 Wi-Fi 6 (802. a/b/g/n/ac/ax) support 024QAM/OFDMA/MU-MIMO
Supports up to 2.4Gbps max data rate
Supports dual band frequency 2.4/5 GHz
Supports channel bandwidth: HT20/HT40/HT80/HT60
Supports PCIe interface
Bluetooth
Bluetooth v5.*
*BT 5. function will be ready in Windows 0 build 904 or later.
Audio
Realtek ALC887 7. Surround Sound High Definition Audio CODEC

Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/92kHz playback


Audio Feature :

LED-illuminated design
Audio Shielding
Dedicated audio PCB layers
Premium Japanese audio capacitors


USB Ports
Rear USB Port ( Total 6 )
2 x USB 3.2 Gen 2 port(s)(2 x Type-A)
4 x USB 3.2 Gen port(s)(4 x Type-A)
Front USB Port ( Total 6 )
2 x USB 3.2 Gen port(s)(2 x Type-A)
4 x USB 2.0 port(s)(4 x Type-A)
Software Features
ASUS Exclusive Software
Armoury Crate

Aura Creator
Aura Sync


AI Suite 3

Performance And Power Saving Utility


TurboV EVO
EPU
Digi+ VRM
Fan Xpert 2+

EZ update


ASUS CPU-Z
AI Charger
DAEMON Tools
Norton Anti-virus software (Free Trial for 60 days)
WinRAR
UEFI BIOS
ASUS EZ DIY

ASUS CrashFree BIOS 3
ASUS EZ Flash 3
ASUS UEFI BIOS EZ Mode


ASUS Special Features
ASUS 5X PROTECTION III

ASUS DIGI+ VRM
ASUS LANGuard
ASUS Overvoltage Protection
ASUS SafeSlot Core
ASUS Stainless-Steel Back I/O


ASUS Q-Design

ASUS Q-DIMM
ASUS Q-Slot


ASUS Thermal Solution

Aluminum heatsink design


AURA Sync

Standard RGB headers
Addressable Gen 2 RGB header


ASUS Lighting Control
Back I/O Ports
x PS/2 keyboard/mouse combo port(s)
x DVI-D
x D-Sub
x HDMI
x LAN (RJ45) port(s)
2 x USB 3.2 Gen 2 (teal blue) (2 x Type-A)
4 x USB 3.2 Gen (blue) Type-A
3 x Audio jack(s)
x ASUS Wi-Fi Module
Internal I/O Ports
x CPU Fan connector(s)
x CPU OPT Fan connector(s)
2 x Chassis Fan connector(s)
2 x Aura RGB Strip Headers
x Addressable Gen 2 header(s)
x USB 3.2 Gen (up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen port(s)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
x M.2 Socket 3 with M key, type 2242/2260/2280/220 storage devices support(SATA &, PCIe 4.0 x4 mode)
x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA &, PCIE 3.0 x 4 mode)
x SPI TPM header
4 x SATA 6Gb/s connector(s)
x S/PDIF out header(s)
x 24-pin EATX Power connector(s)
x 8-pin EATX 2V Power connectors
x Front panel audio connector(s) (AAFP)
x Clear CMOS jumper(s)
x System panel connector
x COM port header
x Speaker connector
Accessories
I/O Shield
2 x SATA 6Gb/s cable(s)
x Supporting DVD
User manual
x Wi-Fi moving antenna
x M.2 SSD screw package(s)
BIOS
256 Mb Flash ROM, UEFI AMI BIOS
Manageability
WOL by PXE
Operating System
Windows®, 0 64-bit
Form Factor
mATX Form Factor
6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
